W1390
D700
H950

181

103

+1/+8

  • General Information

    Internal Dimention: W810 x D570 x H570mm
    With Backsplash 100mm
    Cold: Ventilated
    Motor: Extractable on Right Side For Easy Maintenance or Technical Service
    Interior Bottom: Stamped
    Outside: Inox AISI 441
    Inside: Inox AISI 304
    Worktop: Inox AISI 304
    Back:in Galvanized Steel
    Defrost: Automatic
    Insulation: Polyurethane Water Base 70mm
    Lighting: LED
    Feet: Inox Adjustable
    Double support in Inox for shelves
    – 1 Shelf in Plastified Steel by Door
    Capacity: GN 1/1 – 325x530mm

  • Technical Data

    Code: 801124V0429

    Model: RCG 2 PV ALC Softline

    Width: 1390mm

    Depth: 700mm

    Height: 850/900mm (+100)

    Gross volume: 263

    Liquid volume: 181

    Weight (Kg): 103

    Power: 208W

    Tension | Freq.: 230V - 50Hz

    Consumption: 1621 kwh/year

    Shelves: 2

    Thermostat: Digital

    Gas: R 290

    Option with Backsplash: Yes

    Climate Class: 4

    Temperature Class: M2

    Energy Class: C

  • Shipping Information

    Weight with packaging (Kg): 113

    Dimension (mm): 1430 x 740 x 1000

    Load capacity (unit):

    TIR | 20” | 40”
    54 | 24 | 48

  • Acessories

    Shelf
    Cod. 007067_008

    Shelf Guide
    Cod. 129038_22

    Spacer Shelf
    Cod. 109979_100

    Wheels Kit | 2 Swivel + 2 Swivel with Brake
    Cod. 129001

    Back in Stainless Steel
    Cod. 129039_6
