W600
D700
H1510

101

93

+5/+20

  • General Information

    Internal Dimension: W500 x D545 x H1360mm
    Interior e Exterior: Chapa Plastificada (Skinplate Preto)
    Insulation: Polyurethane Water Base 50mm
    Cold: Ventilated with Automatic Defrost
    Sliding Wired Shelves + 1 Fixed in the Bottom
    – 7 x (532x459mm) + 1 (475x385mm)
    Glass Door with UV Protection
    – Reversible Glass Door (Under Request)
    Lighting: Ambar LED
    Anti-Vibration System
    Active Charcoal Filter
    Locker Included
    4 Rollers + 2 Levellers
    Temperature Set by User

  • Technical Data

    Code: 801038V0206

    Model: CV 350 PV SD Exclusive

    Width: 600mm

    Depth: 700(+40)mm

    Height: 1510mm

    Capacity: 101 Bottles

    Weight (Kg): 93

    Power: 160W

    Tension | Freq.: 230V - 50Hz

    Consumption: 899 kwh/year

    Shelves: 7 + 1

    Noise Level: < 50 dB

    Gas: R 600a

    Climate Class: 4

    Temperature Class: H1

    Energy Class: B

  • Shipping Information

    Weight with packaging (Kg): 103

    Dimension (mm): 620 x 730 x 1660

    Load capacity (unit):

    TIR | 20” | 40”
    63 | 27 | 57

  • Acessories

    Wire Shelf + Sliders Kit
    Cod. 129040V0506

    Bottom Shelf SD
    Cod. 007119V0506

    Active Charcoal Filter
    Cod. 129042
